| Anwendung: | geeignet für Game/Workstation |
| Sockel: | S1156 |
| Chipsatz: | Intel P55 |
| FSB: | |
| Arbeitsspeicher: | 4x DDR3 (1066,1333 MHz) |
| Cardreader | intergiert |
| PCI Steckplätze: | 1x |
| PCI Express 1x: | 1x |
| PCI Express 16x: | 2x |
| Einbauschächte: | 5.25": 2x 3.5": 2x |
| CPU | Intel CPU Intel® Core™ i7 Processor Intel® Core™ i5 Processor Socket LGA 1156 |
| Chipset | Single Chipset: Intel P55 |
| Memory | 4 x DIMM Support max. 16GB |
| Expansion Slots | 1 x PCI 1 x PCI-e x 1 2 x PCI-e x 16 |
| S-ATA | 4 x SATA |
| LAN | 1 x 10/100/1000 Mbps |
| LAN Chip | Realtek RTL8112 |
| Audio | Realtek ALC887 |
| Dimension (mm) W x H x D | 206mm (W) x 461mm (H) x 534mm (D) |
| Drive Bays | 2 x 3.5" 2 x 5.25" |
| Front Panel | 2 x USB2.0 1 x Microphone 1 x Headphone 1 x 16-in-1 Card Reader |
| Rear Panel | 6 x USB 2.0 1 x Line-in/Line-out/Mic-in 1 x PS/2 Keyboard 1 x IEEE 1394 1 x RJ45 LAN 1 x e-SATA 1 x Back Surround LR/Side Surround LR/Center LFE 1 x S/PDIF-out |
| Power Supply | Peak 500W |
| O/S Support | Windows 7 Windows Vista Windows XP |
| Manageability | PXE WOL WOR by Ring PME Wake Up |
| Key Features | ASUS AI manager ASUS AI NET 2 ASUS CrashFree BIOS3 ASUS DriveClone Pro 7 ASUS Express Gate ASUS EZ Flash2 ASUS My Logo2 ASUS Q-Fan ASUS EPU PC Cillin AntiVirus Solution |
| Note | * All specifications are subject to change without notice. Please check with your supplier for exact offers. Products may not be available in all markets. |
